A coffee bar cabinet for a De'Longhi machine should be sized around the exact model and the way its parts move—not the brand name alone. A slim Dedica needs space beside it for a grinder and manual tools. A La Specialista uses more width and height because the grinder is built in. A Magnifica, Dinamica or Eletta may look narrow from the front but need substantial depth plus access for beans, water, milk and cleaning parts.
The practical answer is to measure two things: the machine's closed footprint and its service envelope. The service envelope is the extra space your hands and removable parts need above, behind, beside and in front of the appliance.
The specifications below come from current De'Longhi U.S. pages reviewed August 18, 2026. Model codes and regional versions matter, and specifications can change. Recheck the current product page and the manual for the code printed on your machine before ordering furniture.
Current De'Longhi dimensions at a glance
| U.S. model | Model code | Official dimensions as published | Published weight | System | First cabinet question |
|---|---|---|---|---|---|
| Dedica Maestro Plus | EC950M | 8.15 × 13.62 × 12.9 in, L × D × H in the manual | 13.67 lb | Manual espresso; separate grinder | Can the grinder and tamping zone fit beside the slim body? |
| La Specialista Opera | EC9555M | 14 × 15 × 17.5 in on product page | 28.11 lb | Manual espresso; integrated grinder | Can the hopper, tamper and steam workflow operate below the shelf? |
| Magnifica Start | ECAM22022B | 17 × 9.25 × 14 in on product page | 19.82 lb | Fully automatic; manual frother | Which direction does the current page/manual assign to each number, and can all service parts move? |
| Dinamica Plus | ECAM38085SB | 9.3 × 16.9 × 13.7 in, W × D × H | 21.74 lb | Fully automatic; milk carafe | Is the top deep enough for the 16.9-inch body plus plug and front service? |
| Eletta Explore | ECAM45086S | 10.25 × 17.50 × 15.13 in, W × D × H | 24.69 lb | Fully automatic; hot/cold milk systems | Can a 17.5-inch-deep machine, tall cup and milk-carafe workflow remain accessible? |
The row is not a cabinet-size prescription. It is a shortlist for further measuring. Some current product tables show three dimensions without labeling their order, while other pages explicitly say W × D × H. That is why this guide preserves the manufacturer's wording instead of silently rearranging numbers.
For example, the Dinamica Plus ECAM38085SB page explicitly gives a 9.3-inch width and 16.9-inch depth. Calling it simply “compact” would hide the dimension most likely to challenge a shallow cabinet.
Start with the exact model code
“Dedica,” “Magnifica” and “Dinamica” are family names, not complete measurements. Look for the code on the rating label, order confirmation or support page. Codes such as EC950M, EC9555M and ECAM45086S distinguish products that may have different tanks, milk systems, controls and dimensions.
Use the U.S. page for a U.S. machine. A similarly named international version may use different voltage, accessories or model suffixes. If the product page and the manual appear to disagree, pause the furniture purchase and confirm the current model with De'Longhi support.
Choose the layout by machine type
Dedica: narrow machine, wider complete station
The Dedica Maestro Plus EC950M is only 8.15 inches wide. Its official manual lists the complete dimensions as 8.15 × 13.62 × 12.9 inches in L × D × H order. That makes it attractive for a small coffee cabinet, but the machine is only one part of a manual espresso system.
Place the grinder beside the machine, not behind it. You also need a place to dose or tamp, park the portafilter, position the milk pitcher at the steam wand and set down a wet tool. If those items live on another counter, the machine fits but the coffee station does not.
The Dedica is best suited to a cabinet where side-by-side working width matters more than a tall appliance bay. A shallow overhead shelf can still cause trouble if it blocks the rear water tank or makes refilling awkward. Simulate removing and replacing the tank with the shelf in place.
La Specialista: integrated grinder, larger top-access zone
The La Specialista Opera EC9555M combines grinding and espresso preparation. Its current U.S. page lists dimensions of 14 × 15 × 17.5 inches, a weight of 28.11 pounds and 1600 watts. The page does not label the order of those three dimensions in that row, so verify the manual before turning them into cabinet directions.
An integrated grinder can save the width of a separate appliance. It does not eliminate workspace. Beans must reach the hopper, the portafilter must rotate into the group, the built-in tamping process must remain reachable, and the milk pitcher must move around the steam wand.
Do not place a fixed shelf at the exact closed height of the machine. Test the highest real action: opening or removing the hopper, adding beans and cleaning the grinder area. The useful opening is the height needed for that action, not merely the height of the idle appliance.
Magnifica, Dinamica and Eletta: narrow front, deep service system
De'Longhi's ECAM fully automatic machines grind, dose and brew internally. That reduces loose espresso tools, but it creates a different cabinet problem: repeated service of built-in systems.
The Magnifica Start ECAM22022B has a 60.87-ounce water container, 250-gram bean hopper and grounds container. The Dinamica Plus ECAM38085SB measures 9.3 × 16.9 × 13.7 inches when read from the U.S. W × D × H specification. The Eletta Explore ECAM45086S reaches 17.5 inches deep and supports tall drinks and removable milk systems.
These machines need a clear front path for cups, drip-tray work and routine cleaning. They also need the correct access direction for the water tank and brewing components shown in the exact manual. A cabinet door, raised front lip or decorative tray should not obstruct those movements.
The best layout usually gives the automatic machine its own deep bay, keeps cups and beans in adjacent storage, and leaves one clear landing area in front or beside it. Avoid surrounding the machine with decor that must be moved every time the carafe or water tank is handled.
Map the four-direction service envelope
Before comparing furniture, draw four arrows around the machine.
Above: beans, lids and removable hoppers
Measure with the bean lid open and your hand holding a bag or scoop. If a hopper can be removed, measure that full movement too. A shelf that clears the lid by half an inch may still force you to pull the machine forward for every refill.
Behind: plug, cable bend and rear service
Published depth normally describes the appliance body. It may not include a plug protruding from the wall or a cable that needs a gentle bend. Do not crush the cord between the machine and the backsplash. If the tank or another component moves rearward, include that path as well.
For a complete outlet plan, use the separate coffee bar cabinet outlet and cord management guide. That page handles electrical placement; this one only identifies the space the machine needs.
Beside: steam wand, milk pitcher and side access
Manual espresso models need room to position and remove the pitcher without hitting a side panel. Automatic milk carafes may also need a direct path to and from the refrigerator. Store the pitcher or carafe near that path rather than across the room.
In front: cup, portafilter, tray and cleaning parts
Front space is the most commonly lost zone. The portafilter extends beyond a manual machine during insertion and removal. Automatic machines need room for cups, rinse water and removable parts. A cabinet top that is technically deep enough can still fail if a raised edge, tray or door blocks this work.
Keep a dry landing zone at least large enough for the biggest item you routinely handle—a tall travel mug, milk carafe, water tank or drip tray. The exact size comes from your equipment, not a universal decorating rule.
Calculate cabinet size from the complete system
Use this sequence rather than adding an arbitrary number of inches to the machine.
- Record the closed machine footprint. Use the exact model page and manual.
- Add permanent neighbors. Include a separate grinder, knock box, scale or water treatment device.
- Add the service envelope. Measure lids, tanks, hoppers, handles, wands, trays and carafes at their farthest useful position.
- Preserve one landing zone. Keep it free during normal brewing.
- Check the furniture structure. Use the maker's written top and shelf load ratings.
- Test cords and ventilation. Follow the current appliance manual, not a generic gap copied from another model.
If depth is the constraint, compare your result with the 12-, 16- and 20-inch coffee bar cabinet depth guide. A nominal furniture depth is not always the usable top depth: backsplashes, wall trim, rear rails and door hardware can reduce it.
What can fit on 24-, 30- and 36-inch-wide tops?
These are planning scenarios, not compatibility guarantees. Your measured equipment decides the result.
Around 24 inches: one focused system
A 24-inch top may support a Dedica plus a compact grinder if both measured footprints and a narrow work strip fit. It may also support one automatic machine with cups stored above or inside the cabinet. Do not assume it can hold a La Specialista, syrup display and full tamping kit without crowding.
Around 30 inches: a machine plus a real landing zone
Thirty inches often makes it easier to keep an automatic machine on one side and preserve a clear zone on the other. For a manual system, it may allow grinder, machine and a working strip in one line. Test the steam-wand side before deciding which end the machine occupies.
Around 36 inches: flexible, but not permission to fill every inch
A 36-inch top can separate wet and dry tasks and may suit larger integrated-grinder machines. Its advantage disappears if every open area becomes decor or syrup storage. Reserve the center of the workflow for actual coffee making, then place frequently used accessories at the edges.
Use the complete coffee bar cabinet buying guide to compare construction and placement, then browse coffee bar cabinets only after you have this measured system width and depth. The collection page helps compare furniture; it cannot identify the service envelope of an unknown appliance.
Check load, heat, steam and water
Machine weight is only the starting load. Add water, beans, grinder, mugs, stored supplies and anything mounted above. The La Specialista Opera is listed at 28.11 pounds before those additions; the Eletta Explore is listed at 24.69 pounds before water and beans. Use a written cabinet load rating rather than judging strength from appearance.
Steam should not discharge directly into an unprotected low shelf. Wipe condensation after use and inspect the underside and back panel. The coffee bar cabinet ventilation guide explains how to distinguish operating clearance from passive storage space.
Protect the top from routine drips, but do not use a large mat to hide standing water. Keep the plug area dry, empty trays promptly and move the machine when needed for cleaning. A small washable tray can define a wet zone only if it does not obstruct the feet, vents or removable parts.
Run a five-minute mock-up before buying
Mark the cabinet top on the floor or an existing counter with painter's tape. Add blocks or boxes to represent the machine, grinder and shelf. Then perform these motions:
- pour beans into the hopper without hitting the shelf;
- remove, fill and replace the water tank;
- insert and remove the portafilter, or pull the automatic machine's service parts forward;
- position the largest cup and milk container;
- remove the drip tray and grounds container without clearing the whole top;
- reach the outlet without pinching the cord;
- wipe behind and beside the machine.
If one motion requires lifting or rotating the appliance every day, enlarge the opening or choose a different layout. Occasional movement for deep cleaning is normal; daily movement for water or beans is a design failure.
Frequently asked questions
What cabinet depth works for a De'Longhi espresso machine?
There is no brand-wide depth. Dedica Maestro Plus is about 13.62 inches deep in its EC950M manual, while Dinamica Plus ECAM38085SB is 16.9 inches deep and Eletta Explore ECAM45086S is 17.5 inches deep on their U.S. W × D × H pages. Add the actual plug, front-service and manufacturer-required clearance for your model.
Can a De'Longhi machine go under a cabinet shelf?
Only if the shelf clears the highest operating action and the manual's installation requirements. Test bean filling, hopper removal, water-tank access and cleaning—not just the closed machine height.
Is a Dedica always the best choice for a narrow coffee bar?
Its body is narrow, but a complete manual espresso setup also needs a grinder, tamping area, portafilter and milk-pitcher space. It is a strong narrow-machine option, not automatically the narrowest complete system.
Does an integrated grinder save cabinet space?
It can save side width by replacing a separate grinder. In return, it often needs more top access and may create a taller, heavier appliance. Compare the complete service envelope rather than counting appliances.
Should the machine sit inside a closed cabinet?
Do not operate it in a closed compartment unless the furniture design and the exact appliance instructions explicitly support that use. Heat, steam, removable parts and cord access usually make an open operating position more practical.
The short answer
The right coffee bar cabinet for a De'Longhi machine is the one that fits the exact model while it is being used and cleaned. Start with the model code, confirm the current U.S. dimensions, map every moving part in four directions, add the grinder and milk workflow, then test the layout at full scale. That process is more reliable than any “De'Longhi compatible” label—and it leaves room for coffee making instead of merely storing a machine.
